THJK436150WL - General Electrics - Molded Case Circuit Breakers

Feed-Thru - 150 Amp - 3 Pole - 600 V

GE SKU: THJK436150WL

Images are for reference only

THJK436150WL - General Electrics - Molded Case Circuit Breakers

Feed-Thru - 150 Amp - 3 Pole - 600 V

GE SKU: THJK436150WL
/
  • In stock and ready to ship
  • Inventory on the way
Condition
Shipping calculated at checkout.
  • Secure transaction
  • FREE & fast shipping on orders over $49
  • 1 year warranty
  • 30 day returns

Returns are easy

You may return items within 30 days of delivery for a refund.

View our return policy

FREE Shipping on orders over $49.

Simply Breakers offers one to five day delivery in the United States. The variation depends on the chosen shipping speed and the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Simply Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Simply Breakers provides a comprehensive 1-year warranty on both new and reconditioned products. Rest assured, all products are authentic OEM (original equipment manufacturer). Extended warranties are available upon request.

Overview

Product Specifications - THJK436150WL - General Electrics Molded Case Circuit Breakers

  • Part Number:

    THJK436150WL

  • Manufacturer:

    General Electric

  • Family:

    J600 Line

  • Pole:

    3

  • Amp

    150

  • Volt:

    600

  • Phase:

    3

  • Category:

    Molded Case Circuit Breakers / 3-Pole

  • Connection:

    Feed-Thru

  • Type:

    THJK

  • Functions:

    LI - Long-Time and Instantaneous

  • Protection:

    Thermal Magnetic

  • AIC Ratings:

    35kA@480V

Dimensions

  • Dimensions (HxWxD):

    3.81 x 8.25 x 10.12

  • Weight:

    17.4 lb

Standards

CSA Approved logo

Product Description - THJK436150WL - General Electrics Molded Case Circuit Breakers

The THJK436150WL, part of the J600 Line by General Electric, is a versatile molded case circuit breaker offering a Type THJK configuration. With 3 poles (3P) and 3 phases (3PH), it provides a 150A current rating at 600V, ensuring efficient protection for various applications. The breaker features a commendable 35kA@480V interrupting capacity and includes line and load side lug terminals, as well as an interchangeable trip unit. Operating at 40ºC, the Feed-Thru design and Thermal Magnetic technology make it a reliable choice for applications requiring high interrupting capacity.
