Overview
Product Specifications - AN16AN0EC - Eaton Cutler-Hammer Starter
-
Part Number:
AN16AN0EC -
Manufacturer:
-
Pole:
3 -
Amp:
9A -
Phase:
3 -
Category:
-
HP Rating Max:
1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V
-
Coil:
208 Vac, 60 Hz -
Coil Voltage:
208 Vac, 60 Hz -
Special Features:
Starter w/C306 bi-metal OLR
Dimensions
-
Dimensions (HxWxD):
4.61 in x 3.31 in x 4.38 in -
Weight:
2.6 lb
Standards
Product Description - AN16AN0EC - Eaton Cutler-Hammer Starter
Eaton Freedom NEMA motor control starter,Non-Reversing Starter, Reset Overload Relay, 1/3 hp at 115V,1 hp at 230V, 1-1/2 hp at 208,240V, 2 hp at 480,600V maximum horsepower, 208V/60 Hz coil voltage, 9A, Three-pole, Size 00
