BAB3030HS - Eaton - 30 Amp Shunt Trip Circuit Breaker
Bolt-On - 30 Amp - 3 Pole - 240 Volt
Eaton Cutler-Hammer
SKU: BAB3030HS
Images are for reference only
Returns are easy
You may return items within 30 days of delivery for a refund.
FREE Shipping on orders over $49.
Simply Breakers offers one to five day delivery in the United States. The variation depends on the chosen shipping speed and the warehouse location for the product(s).
Same Day Shipping
We strive to ship out your items within one business day.
In rare circumstances, Simply Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.
Simply Breakers provides a comprehensive 1-year warranty on both new and reconditioned products. Rest assured, all products are authentic OEM (original equipment manufacturer). Extended warranties are available upon request.
BAB3030HS - Cutler-Hammer Bolt-On Molded Case Circuit Breaker
This Eaton Cutler-Hammer Shunt Trip Breaker is a compact three-pole thermomagnetic circuit breaker rated at 30 amps at 40 degrees and 240 Vac, with a breaking current rating of 10,000 amps, a 120V, 208V, 240V shunt trip, the switch is UL listed and CSA certified.
Specifications:
- Product Name: Quicklag Industrial Thermal-Magnetic Circuit Breaker
- Product Length: 4 in
- Product Height: 3.5 in
- Product Width: 3.7 in
- Product Weight: 1.25 lb
- Certifications: CSA Certified , UL Listed
- Catalog Notes: HACR rated
- Mounting: Bolt-on
- Special Features: 120V, 208V, 240V shunt trip
- Interrupt Rating: 10 kAIC
- Type: Quicklag
- Circuit Breaker Type: BAB
- Quantity: Q32
- Voltage Rating: 240V
- Amperage Rating: 30A
- Trip Type: Non-Interchangeable
- Number Of Poles: Three-pole
- Authentic Eaton/Cutler-Hammer Product
- Dimensions (H x W x L): 3.5" x 3.7" x 4"
- 3 phase
