800H-UR29 - Allen-Bradley - Potentiometer Switch
Allen-Bradley
SKU: 800H-UR29
Images are for reference only
Returns are easy
You may return items within 30 days of delivery for a refund.
FREE Shipping on orders over $49.
Simply Breakers offers one to five day delivery in the United States. The variation depends on the chosen shipping speed and the warehouse location for the product(s).
Same Day Shipping
We strive to ship out your items within one business day.
In rare circumstances, Simply Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.
Simply Breakers provides a comprehensive 1-year warranty on both new and reconditioned products. Rest assured, all products are authentic OEM (original equipment manufacturer). Extended warranties are available upon request.
800H-UR29 - Allen-Bradley Potentiometer Switch
Potentiometer, 10 Kilo-Ohms, Resistance, 300 Volt, AC/DC, 2 Watt Maximum, NEMA 4/4X/13, 30 mm
Innovative and unique, Allen-Bradley Bulletin 800H push buttons are designed and constructed for the most demanding industrial environments. These bold, attractive buttons are rugged and highly functional. Catalog item 800H-UR29 from Rockwell Automation is a 30 mm push button potentiometer. It is a 10 K potentiometer unit. For full product details, please see the sections below. Allen-Bradley is a trademark of Rockwell Automation, Inc.
- Manufacturer: Allen-Bradley
Specifications
- Terminations with finger safe covers: No
- Enclosure compatibility (NEMA type): 1, 4, 4X, 12, 13
- Hole diameter: 30.5 mm
- Suitable for illumination: No
- Operator mechanical design life (cycles, min.): 25000
- Operator function: Single turn
- Vibration: 10 G maximum
- Potentiometer module termination wire range: 14 - 18 AWG (x2)
- Shock: 100 G (no damage)
- Potentiometer module termination tightening torque: 6 - 7 lb - in / 0.7 - 0.8 N-m
- Potentiometer module power rating: 2 W
- Potentiometer module input voltage: 300V AC/DC (6V DC min)
- Potentiometer module resistance rating: 10K Ohm
- Type of electric connection: Screw connection
- Operator construction/material: Plastic
- Operator cap/button shape: Round
- Operator cap color: Black
- Operator cap/button material: Plastic
- Operator cap type: Standard knob
- Operator type: Potentiometer unit
- Hazardous location rating: No
- Humidity: 50 %
- Operating temperature: -25 °C
- Storage temperature: -40 °C
- Certifications: ABS, CCC, CE, CSA, EAC, GOST, UL
